Περιγραφή
DC Electrical Characteristics
- STC Power Rating – 455W
- PTC Power Rating – 424.77W 1
- STC Power per unit of area – 19.4W/ft2 (209.3W/m2)
- Peak Efficiency – 20.93%
- Power Tolerances – 0%/+5%
- Number of Cells – 72
- Nominal Voltage – not applicable
- Imp – 10.92A
- Vmp – 41.7V
- Isc – 11.66A
- Voc – 49.5V
- NOCT – 45°C
- Temp. Coefficient of Isc – 0.05%/K
- Temp. Coefficient of Power – -0.35%/K
- Temp. Coefficient of Voltage – -0,134V/K
- Series Fuse Rating – 20A
- Maximum System Voltage – 1500V
Mechanical Characteristics
- Type Monocrystalline – Silicon
- Output Terminal Type Multicontact Connector Type 4
- Output Cable Wire Gauge – 12 AWG
- Output Cable Wire Type – PV Wire
- Output Cable Wire Length – 7,9in (200mm)
- Frame Color – Clear
- Backsheet Color – White
- Length – 82,4in (2.094mm)
- Width – 40,9in (1.038mm)
- Depth – 1,4in (35mm)
- Weight – 51,4lb (23,3kg)
- Installation Method – Rack-Mounted
