Panel Longi Solar 430W LR4-72HBD-430M GRADE B
Out of Stock

Panel Longi Solar 430W LR4-72HBD-430M GRADE B

300,00€

Electrical Data
Model
LR4-72HBD-425M
LR4-72HBD-430M
LR4-72HBD-435M
LR4-72HBD-440M
Peak Power Watt- Pmax (W)
425
430
435
440
Maximum Power Voltage- Vmpp (V)
40.4
40.6
40.8
41.0
Maximum Power Current- Impp (A)
10.52
10.60
10.66
10.73
Open Circuit Voltage- Voc (V)
48.7
48.9
49.1
49.2
Short Circuit Current- Isc (A)
11.22
11.30
11.36
11.45
Module Efficiency (%)
19.6
19.8
20.0
20.2
Power Output Tolerance (W)
0 ~ +5
STC
Irradiance 1000W/m², Cell temperature 25℃,  Air Mass AM1.5
Operational Temperature
-40~+85℃
Maximum System Voltage
1500V DC(IEC), 1500V DC(UL)
Max Series Fuse Rating
20A
Temperature Coefficient of Pmax
-0.35%/℃
Temperature Coefficient of Voc
-0.284%/℃
Temperature Coefficient of Isc
+0.050%/℃





Εξαντλημένο / Παράδοση έως 30 ημέρες

Κωδικός προϊόντος: Panel Longi Solar 430W LR4-72HBD-430M GRADE B Κατηγορία: Μάρκες:

Περιγραφή

Place of Origin:
Guangdong, China
Brand Name:
Longi Solar
Model Number:
LR4-72HBD-430M
Type:
PERC, Half Cell, Bifacial, Double-glass
Panel Dimensions:
2131*1052*35mm
Panel Efficiency:
20%
Certificate:
TUV/IEC61215/IEC61730/CEC/CE/PID/ISO
Warranty:
25 Years
Item name:
bifacial solar panels 430w
Solar cell:
mono 156.75*156.75mm
Weight:
29.5 KG
Junction Box:
IP68.three diodes
Frame:
Anodized Aluminium Alloy
Front Glass:
Dual glass 2.0mm tempered glass
Cable:
4mm2
Connector:
MC4 Compatible Connector
Power tolerance:
0~+3%
Application:
Solar Panel System

Επιπλέον πληροφορίες

Βάρος 37 κ.
