Περιγραφή
| Technology: | Monocrystalline (Mono) |
| Dimensions: |
78.27 x 39.57 x 1.57 inches |
| Weight: | 49.82 lbs |
| Number of Cells: | 72 (6 x 12) |
| Glass: | 3.2 mm |
| Junction Box: | IP67, 3 Diodes |
| Connector: | QC 4.10 (1000 V), QC 4.10-35 (1500V) |
| Operating Temperature: | -40°C ~+85°C |
| Electrical Data |
|
| Rated Maximum Power (Pmax): | 390 Watts |
| Open Circuit Voltage (Voc): | 49.35 Volts |
| Maximum Power Voltage (Vmp): | 40.21 Volts |
| Short Circuit Current (Isc): | 10.22 Amps |
| Maximum Power Current (Imp): | 9.7 Amps |
| Module Efficiency: | 19.5% |
